This Raspberry Pi product is a series of small computer boards that we use to offload data from our enDAQ Sensors directly to a USB Stick connected to the module.
PLEASE NOTE: LONGER LEAD TIMES
Due to the global chip shortage, some of our products require a longer lead time than the usual 2 business days + shipping. We sincerely apologize for the inconvenience and are working tirelessly to transition to a more readily available microprocessor. In the meantime, if you have any questions, please do not hesitate to reach out to our Customer Success Team.
Click for AVAILABLE PRODUCTS
|Accelerometer Type||Range||Sampling Rate||Bandwidth||Noise||Resolution|
|Sensor||Measurement Range||Resolution||Sampling Rate|
|Gyroscope||2000°/s||0.06 °/s||0 (oﬀ) to 200 Hz|
|Magnetometer||± 1300 µT||0.3 µT||0 (oﬀ) to 10 Hz|
|Temperature||-40 to 85 °C||0.01 °C||0 (oﬀ) to 10 Hz|
|Pressure||1 to 200 kPa||1.6 Pa||0 (oﬀ) to 10 Hz|
|Humidity||0 to 100 %RH||0.04% RH||0 (oﬀ) to 10 Hz|
|Light||0 to > 20 uV||<100 mlx||0 (oﬀ) to 4 Hz|
|Recommended Storage Temperature||15°C to 30°C (59°F to 86°F)||Recharging Temperature 0°C to 45°C (32°F to 113°F)|
|Humidity||0 to 95 %RH||Non-Condensing|
|Pressure||20 kPa to 110 kPa (2.9 psi to 16.0 psi)||Absolute Pressure|
|Shock Limit||>3,000 g||Refer to Shock Report (PDF)|
|No Electric Field Susceptibility||2 MHz to 18 GHz @ 200 V/m||Refer to EMI Test Report (PDF)|
|No Magnetic Field Susceptibility||30 Hz to 100 kHz||Refer to EMI Test Report (PDF)|
|Sample Rate||Storage Capacity||Continuous Recording||Main Accel. Trigger||2nd Accel. Trigger||Periodic/Time Trigger|
Engineered to provide an IP68 rating. It also comes equipped with two rectangular mounting magnets each with a 54.1 lb pulling force.
